(16) 10/100/1000Base-T PoE+ Ports + (4) 100/1000Base-X SFP Slots + (2) 1G/10GBase-X SFP+ Slots
(24) 10/100/1000Base-T PoE+ Ports + (4) 100/1000Base-X SFP Slots + (4) 1G/10GBase-X SFP+ Slots
The SISPM1040-3000-L3 Series managed Layer 3 (L3) hardened Gigabit Ethernet PoE switches offer powerfulLayer 2 and Layer 3 features and performance required to meet the demands of Smart City and Utility,Transportation, Security and Surveillance applications where performance and reliability across a wide range oftemperatures is required. The SISPM1040-3000-L3 Series are designed to support current and future Internet ofThings (IoT) applications with their non-blocking / wirespeed performance, wide operating temperature range of-40°C to 75°C for outdoor and indoor environments.
Device management is made simple with Lantronix ConsoleFlow™. The ConsoleFlow Cloud device managerprovides cloud-based control of the Lantronix SISPM1040-3000-L3 Series network switches. ConsoleFlowCloud provides a single pane of glass to securely deploy, monitor and manage Lantronix network switches andconnected IT equipment. ConsoleFlow Cloud features True Zero-Touch automation, simplifying onboardinglogistics and provisioning new devices while eliminating remote or on-site visits and reducing operational costs.In addition, the native mobile apps for iOS® or Android™ platforms provide users the freedom to monitor andremotely connect to any device while on the go.
- General Information
- Manufacturer
- Lantronix, Inc
- Manufacturer Website Address
- http://www.lantronix.com
- Brand Name
- Lantronix
- Product Series
- SISPM1040-3000-L3
- Product Type
- Layer 3 Switch
- Warranty
- Limited Warranty
- 5 Year
- Interfaces/Ports
- Total Number of Network Ports
- 24.0
- Modular
- Yes
- Stack Port
- No
- Network (RJ-45)
- Yes
- Port/Expansion Slot Details
- 24 x Gigabit Ethernet Network PoE+
- 4 x Gigabit Ethernet SFP
- 4 x 10 Gigabit Ethernet SFP+
- Media & Performance
- Media Type Supported
- Twisted Pair
- Optical Fiber
- Ethernet Technology
- 10 Gigabit Ethernet
- Network Technology
- 10GBase-X
- 10/100/1000Base-TX
- 100/1000Base-FX
- I/O Expansions
- Total Number of Expansion Slots
- 8.0
- Expansion Slot Type
- SFP+
- SFP (mini-GBIC)
- Shared SFP Slot
- No
- Number of SFP Slots
- 4
- Network & Communication
- Layer Supported
- 4
- Networking Standards
- IEEE 802.3ah
- IEEE 1588v2
- IEEE 802.3x
- IEEE 802.1ab
- IEEE 802.3
- IEEE 802.1s
- Management & Protocols
- Manageable
- Yes
- Power Description
- PoE (RJ-45) Port
- Yes
- PoE Budget
- 370 W
- Input Voltage
- 57 V DC
- 52 V DC
- 120 V AC
- 230 V AC
- Power Source
- PoE+
- AC
- DC
- Power Consumption
- 15 W
- Physical Characteristics
- Height
- 1.7"
- Width
- 17.4"
- Depth
- 11.8"
- Weight (Approximate)
- 11 lb
- Miscellaneous
- Package Contents
- SISPM1040-3000-L3 Layer 3 Switch
- Power Cord North America
- Application/Usage
- Network
- IP Camera
- Wireless Access Point
- Security
- Surveillance
- Workplace
- Environmentally Friendly
- Yes
- Environmental Compliance
- Registration, Evaluation, Authorization and Restriction of Chemicals (REACH)
- Restriction of Hazardous Substances (RoHS)
- Waste Electrical and Electronic Equipment Directive (WEEE)
