REAL-TIME STATUS SCREEN
The crystal-clear digital screen displays the temperature and usage of your system's CPU in real time, and there is also a high temperature warning. The display is controlled via a simple application that only requires an open USB 2.0 header.
PROVEN AK ZERO DARK DESIGN
An all-black edition of the dominant AK620 high-performance CPU cooler. The same premium quality materials, featuring six advanced copper heat pipes, a pure copper coldplate, a dense dual-tower heat sink, and two silent FDB fans, produce a powerful winning formula for high performance cooling in a ZERO DARK raven design.
UNLOCKED POTENTIAL
Achieve peak performance on your CPU with substantial cooling capacity for high frequency overclocking. The AK620 DIGITAL features maximum heat dissipation power and improved airflow to lower temperatures during demanding system applications.
COOL, QUIET, AND POWERFUL
Two powerful PWM fans with superior fluid dynamic bearings offer low noise operation without losing cooling output for a perfect balance.
SIMPLE AND SECURE INSTALLATION
The provided all metal mounting bracket provides an easy installation process that ensures proper contact and equal pressure on both Intel and AMD platforms.
- General Information
- Manufacturer
- Deepcool Industries Co., Ltd
- Manufacturer Website Address
- http://www.deepcoolglobal.com
- Brand Name
- Deepcool
- Product Type
- Cooling Fan/Heatsink
- Warranty
- Limited Warranty
- 3 Year
- Fan Information
- Number of Fans
- 2
- Fan Bearing Type
- Fluid Dynamic Bearing
- Fan Speed (Min)
- 500 rpm
- Fan Speed (Max)
- 1850 rpm
- Maximum Airflow
- 516.1 gal/min
- Noise Levels (A-Weighted)
- 28 dB(A)
- LED Color
- ARGB
- Maximum Air Pressure
- 2.19mmH2O
- Heatsink Information
- Number of Heat Pipes
- 6
- Compatible Intel Socket
- R4 LGA-2066
- LGA 2011-v3
- R LGA-2011
- LGA-1700
- LGA-1200
- H4 LGA-1151
- H3 LGA-1150
- H2 LGA-1155
- Compatible AMD Socket
- AM4
- AM5
- Interfaces/Ports
- Connectors
- 4-pin PWM
- 3-pin(+5V-D-G)
- 9-pin USB 2.0
- Power Description
- Maximum Power Consumption
- 1.44 W
- Rated Current
- 120 mA
- Physical Characteristics
- Color Family
- Black
- Product Color
- Black
- Product Material
- Copper
- Maximum Fan Diameter
- 4.72"
- Heatsink Height
- 6.18"
- Heatsink Width
- 4.33"
- Fan Height
- 0.98"
- Fan Width
- 4.72"
- Height
- 6.4"
- Width
- 5.4"
- Weight (Approximate)
- 3.28 lb
- Miscellaneous
- Package Contents
- AK620 Digital
- Metal Mounting Bracket
- Features
- Dissipates the Heat
- Application/Usage
- Processor
- CPU
